Copper Coil Compressed Air Dryer

Back to Product List

Designed to drain sludge and rust laden condensate in compressor room equipment and pipeline.

SALIENT FEATURES:

  • Designed and built taking into consideration the high reduction of energy consumption
  • Robust frame
  • Limited pressure drop
  • Low power consumption
  • High efficiency refrigeration compressor
  • Dew point extremely constant functionally even under extreme working conditions(ambient temperature 50°C)

Get a Quote Contact Us



General  Features

Schematic Diagram

Technical Specifications

BASE MODEL MODEL VARIANCE NOMINAL CAPACITY ELECTRICAL CONNECTION AIR CONNECTION RATE POWER KW OVERALL DIMENSION NET WEIGHT
E F CFM m3/hr 220V/1P/50HZ 415V/3P/50HZ IN/OUT AIR COOLED WATER COOLED mm Kg.
2KD 004   40 68   ½"BSP 0.29   360x425x550 47
2KD 006   60 102   ½"BSP 0.46     47
2KD 008   80 136   1"BSP 0.89   550x450x685 80
2KD 010   100 170   1"BSP 0.89   500x600x685 85
2KD 015   150 255   1"BSP 1.67   500x600x685 85
2KD 020   200 340   1½"BSP 1.67   700x700x830 120
2KD 025   250 425   1½"BSP 1.73   700x700x830 135
2KD 030   300 510   1½"BSP 1.73   700x700x830 135
2KD 040   400 680   2"BSP 2.2   900x900x1230 170
2KD 050   500 850   2"BSP 2.2   900x900x1230 180
2KD 060   600 1020   2½"BSP 4.5   750x100x1400 250
2KD 075 750 1275   3" NB FLG 4.7 4.2 900x1300x1725 350
2KD 100 1000 1700   4" NB FLG 6.0 5.0 900x1300x1725 400
2KD 125 1250 2125   4" NB FLG 7.5 5.0 900x1300x1725 425
2KD 150 1500 2550   5" NB FLG 8.8 6.3 1300x1800x1650 650
2KD 200 2000 3400   6" NB FLG 12.2 9.5 1300x1800x1900 800
2KD 250 2500 4250   6" NB FLG 13.9 11.0 1300x1800x1900 850

* Product Design and specifications are subject to change due to constant upgradation.

Specification

  • Product Range    20-2500 (E - Air cooled)
  • Product Range    750-2500 cfm (F - Water cooled)
  • Working pressure range    7-16Kg/cm (g)
  • Max.Inlet temperature    45°C
  • Outlet temperature range   30-35°C
  • Pressure Dew point at outlet    2-4°C
CC - COPPER COIL SERIES
  • Tube in tube copper heat exchanger.
  • Centrifugal moisture separator inbuilted.
  • Low pressure drop.
  • Easy access to key components for service.
